4′, 5′ & 6′ Wide Specs:

  • Single 2,990 lbs. Leaf Spring Axle
  • White .024 Aluminum Exterior with Matching Screws
  • 2″ Ball Coupler
  • 4-way Round plug
  • LED Strip Tail Lights
  • Interior 12v Dome Light
  • Aluminum teardrop Fenders with LED Lights
  • 24″ ATP Stone Guard on Front
  • Galvalume Roof System
  • Manual Crank Roof or Side Vents
  • 14″ x 1″ x 1″ Steel Tube in Ceiling
  • 1″ x 1″ Steel Tube in Walls
  • 2″ x 4″ Steel Tube Mail Rails
  • Ceiling Members 24″ On Center
  • Floor Members 16in On Center
  • 2,000 lbs. Tongue Jack
  • Wall Members 16″ On Center
  • V-Nose with Vertical ATP Trim
  • 3/8″ Plywood Walls
  • 3/4″ Plywood Floor
  • No Side Door on 4′ Models
  • 24″ RV Style Side Door with Flush Lock (5′ Models)
  • 32″ RV Style Side Door with Flush Lock (6′ Models)
  • Approximate Interior Height Varies By Width
  • 2″ x 15″ Radial Tires
  • 2x Silver Powder Coated Modular Style Steel Rim

7′ & 8.5′ Wide Specs:

  • Tandem 3,500 lbs. Leaf Spring Axle with Brakes
  • White .024 Aluminum Exterior with Matching Screws
  • 2-5/16″ Ball Coupler
  • 7-way Round plug
  • LED Strip Tail Lights
  • Interior 12v Dome Light
  • Aluminum teardrop Fenders with LED Lights
  • 24″ ATP Stone Guard on Front
  • Galvalume Roof System
  • Manual Crank Roof or Side Vents
  • 14″ x 1″ x 1″ Steel Tube in Ceiling
  • 1″ x 1″ Steel Tube in Walls
  • 2″ x 4″ Steel Tube Mail Rails
  • Ceiling Members 24″ On Center
  • Floor Members 16in On Center
  • 2,000 lbs. Tongue Jack
  • Wall Members 16″ On Center
  • V-Nose with Vertical ATP Trim
  • 3/8″ Plywood Walls
  • 3/4″ Plywood Floor
  • 32″ RV Style Side Door with Flush Lock (7′ Models)
  • 36″ RV Style Side Door with Flush Lock (8.5′ Models)
  • Approximate Interior Height – 6 ft 3″ (75in)
  • 4″ x 15″ Radial Tires
  • 4x Silver Powder Coated Modular Style Steel Rim

Contact us today for your free dealer application!

Available Trailer Sizes

We specialize in building trailers with the following sizes:

4′ Models5′ Models6′ Models7′ Models8.5′ Models
4×65×66×87×108.5×12
4×85×86×107×128.5×14
5×106×127×148.5×16
5×126×147×168.5×18
7×188.5×20
7×208.5×22
8.5×24
8.5×26
8.5×28
8.5×30
8.5×32
8.5×34
8.5×36
